Product Description
The VEP-P screw flat face coupling series is the Stucchi solution for hydraulic applications requiring high operating pressures and connection with residual pressure trapped in the circuit.
The screw connection system eliminates the premature wear or brinnelling typically associated with locking ball connection systems when used in high impulse circuits. The triple valve system allows connection of the coupling safely even in the presence of high internal residual pressure and at the same time eliminates fluid loss during the connection-disconnection process.
- Valving style: Flat Face
- Interchange: Stucchi profile
- Available sizes: from 1/4" to 2"
- Flow rate: Up to 1000 L/Min
- Operating pressure: Up to 600 bar
- Material: High strength carbon steel
- Connection system: Screw
- Typical use: Outdoor
